Water Jets IPX5 6.3mm Water Jets IPX6 12.5mm - EN 60745

Large Image : Water Jets IPX5 6.3mm Water Jets IPX6 12.5mm - EN 60745

Product Details:

Place of Origin:	Shenzhen China
Brand Name:	Julixing
Certification:	CNAS Test Report
Model Number:	LX-IPX5/6

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Contacts us
Delivery Time:	7-12 Days
Payment Terms:	T/T,Western Union
Supply Ability:	500 Set per month

Contact Now

Detailed Product Description

Types Of Companies:	China Wholesale	Packaging Details:	Standard Packing
Incoterms:	CFR	MOQ:	1 Set
More Products:	Www.china-item.com	Contact Email:	Sales@china-item.com
Product Type:	Testing Equipment

IEC60529 Spray water test Nozzle, IPX56 water Jet Nozzle

Test Set consists of a jet handle that is equipped with a pressure gauge and an easy-to-adjust flow valve.

The interchangeable nozzles assemble easily to the jet handle. The nozzles are made from stainless steel.

Item	IPX5	IPX6
Water supply	Water flow rate > 12.5L/min±5% clean water witho ut inclusion. It can be achieved by the stainless steel water tank and pressurized equipment.	Water flow rate > 100L/min±5% clean water witho ut inclusion. It can be achieved by the stainless steel water tank and pressurized equipment.
The nozzle diameter	6.3 mm	12.5 mm
Water flow	12.5±0.625L/min, Flow meter is adjustable.	100±0.625L/min, Flow meter is adjustable.
Testing time	Not less than 1min/m2 (not less than 3 mins)
Environment requirements	Dedicated IP waterproof test room whose width is more than 3m, With good function of inflow and drainage. Wall installation.
The distance from jet nozzle to enclosure	2.5~3m
Pressure Gauge	0 - 2.5 bar ( 0 - 0.25 MPa )
Reference standards	IEC60529,IEC60598-1,IEC60335-1,IEC60745-1
Nozzle Material	Stainless Steel
Include	Pressure gauge, Stainless steel nozzle IPX5 and IPX6, Valve for water flow regulation and shut off, Hose connector.

Company introduction

Shenzhen Julixing Instruments Co., Ltd. are specialized in manufacturing special, custom built, test and measuring equipment for products testing as per international norms and offering calibration services and related information. Our products and services are used by research & development establishments, test laboratories, defense establishments, government institutions & manufacturing industries to fulfill the clients' requirements.

If you require testing equipment to test products such as home appliances, electrical accessories like switches, sockets, connectors, etc. industrial & road lighting luminaires, automobile lighting systems or related categories, we can provide the solutions you need.
